24 Strand 900 µm Tight Buffer Multimode OM3 50/125 TiniFiber® Micro Armor + Steel Braid BLACK PLENUM-UV (PVC) Indoor/Outdoor Premise, Duct, Conduits, and Patch
Applications: Indoor/Outdoor Premise, Duct, Conduits, and Patch
TF24-OM3-PLO900
Specification
| Strand Count | 24 |
| Fiber Type | |
| Jacket Type | Plenum |
| Construction | 900 µm Tight Buffer |
| Water Block | Yes |
| Armor | Micro Armor + Steel Braid |
| Maximum Attenuation | 3.0 dB/km @ 850 nm | 1.0 dB/km @ 1300 nm |
| Maximum Tensile Strength | 700 N | 300 N |
| Maxumum Crush Resistance | 20 kN/m | 5 kN/m |
| Minimum Bend Radius | 20D | 10D |
| Nominal Outer Diameter | 11.0±0.5 |
| Cable Weight | 145.5 kg/km (~98 lbs/kft) |
TiniFiber® Micro Armor Fiber™ Key Features
| Feature | Benefits |
|---|---|
| Micro Armor Fiber™ |
1. The smallest OD of any armor compared to conventional optical fiber cable in size and flexibility 2. Lightest and smallest armor makes routing and installation faster and easier 3. Cables are up to 65% smaller and 75% lighter than conventional Aluminum Interlocking Armor (AIA) |
| Encased Stainless Steel Coiled Tubular Armor |
1. Provides the strongest armor with smallest bend radius and designed for all indoor & outdoor conditions 2. Crush and rodent resistance |
| Outer Jackets | 1. All jackets and colors for Riser, Plenum, Indoor/Outdoor, LSZH, Burial & Industrial projects |
| Multimode/Single Mode Fibers |
1. OS2, OM1, OM3, OM4 from 1 to 144 Fibers (250m/900m/Ribbon) 2. Compatible with all standard connectors |
| Kevlar | 1. Adds tensile strength and flexibility |
