144 Strand 6x24f 250 µm Sub-unitized Singlemode OS2 9/125 TiniFiber® Micro Armor + Steel Braid YELLOW PLENUM (PVC) Indoor Premise, Duct, Conduits, and Patch
Applications: Indoor Premise, Duct, Conduits, and Patch
TF144-OS2-PL
Specification
| Strand Count | 144 |
| Fiber Type | Corning ClearCurve® LBL G657A2 |
| Jacket Type | Plenum |
| Construction | 250 µm Sub-unitized |
| Water Block | No |
| Armor | Micro Armor + Steel Braid |
| Maximum Attenuation | 0.4 dB/km @ 1310 nm | 0.3 dB/km @ 1550 nm |
| Maximum Tensile Strength | 1400 N | 600 N |
| Maxumum Crush Resistance | 20 kN/m | 5 kN/m |
| Minimum Bend Radius | 20D | 10D |
| Nominal Outer Diameter | 14.5±0.5 |
| Cable Weight | 205 kg/km (~138 lbs/kft) |
TiniFiber® Micro Armor Fiber™ Key Features
| Feature | Benefits |
|---|---|
| Micro Armor Fiber™ |
1. The smallest OD of any armor compared to conventional optical fiber cable in size and flexibility 2. Lightest and smallest armor makes routing and installation faster and easier 3. Cables are up to 65% smaller and 75% lighter than conventional Aluminum Interlocking Armor (AIA) |
| Encased Stainless Steel Coiled Tubular Armor |
1. Provides the strongest armor with smallest bend radius and designed for all indoor & outdoor conditions 2. Crush and rodent resistance |
| Outer Jackets | 1. All jackets and colors for Riser, Plenum, Indoor/Outdoor, LSZH, Burial & Industrial projects |
| Multimode/Single Mode Fibers |
1. OS2, OM1, OM3, OM4 from 1 to 144 Fibers (250m/900m/Ribbon) 2. Compatible with all standard connectors |
| Kevlar | 1. Adds tensile strength and flexibility |
