6 Strand 900 µm Tight Buffer Singlemode OS2 9/125 TiniFiber® Micro Armor + Steel Braid YELLOW RISER (PVC) Indoor Premise, Duct, Conduits, and Patch
Applications: Indoor Premise, Duct, Conduits, and Patch
TF6-OS2-PVC
Specification
| Strand Count | 6 |
| Fiber Type | Corning ClearCurve® LBL G657A2 |
| Jacket Type | Riser |
| Construction | 900 µm Tight Buffer |
| Water Block | No |
| Armor | Micro Armor + Steel Braid |
| Maximum Attenuation | 0.5 dB/km @ 1310 nm | 0.5 dB/km @ 1550 nm |
| Maximum Tensile Strength | 600 N | 200 N |
| Maxumum Crush Resistance | 30 kN/m | 5 kN/m |
| Minimum Bend Radius | 20D | 10D |
| Nominal Outer Diameter | 6.0±0.5 |
| Cable Weight | 56 kg/km (~38 lbs/kft) |
TiniFiber® Micro Armor Fiber™ Key Features
| Feature | Benefits |
|---|---|
| Micro Armor Fiber™ |
1. The smallest OD of any armor compared to conventional optical fiber cable in size and flexibility 2. Lightest and smallest armor makes routing and installation faster and easier 3. Cables are up to 65% smaller and 75% lighter than conventional Aluminum Interlocking Armor (AIA) |
| Encased Stainless Steel Coiled Tubular Armor |
1. Provides the strongest armor with smallest bend radius and designed for all indoor & outdoor conditions 2. Crush and rodent resistance |
| Outer Jackets | 1. All jackets and colors for Riser, Plenum, Indoor/Outdoor, LSZH, Burial & Industrial projects |
| Multimode/Single Mode Fibers |
1. OS2, OM1, OM3, OM4 from 1 to 144 Fibers (250m/900m/Ribbon) 2. Compatible with all standard connectors |
| Kevlar | 1. Adds tensile strength and flexibility |
